项目 |
Item |
UN-2.6 |
UN-2.97 |
|
点间距 |
Pixel pitch |
2.604mm |
2.976mm |
|
模组尺寸 |
Module size |
250*250mm |
250*250mm |
|
模组分辨率 |
Module resolution |
96x96 |
84x84 |
|
物理密度 |
Physical density |
147456 dots/m2 |
112896 dots/m2 |
|
灯珠类型 |
LED type |
SMD1415 |
SMD1415 |
|
箱体尺寸 |
Cabinet size |
500*500(1000)x84mm |
500x500(1000}x84mm |
|
箱体分辨率 |
Cabinet resolution |
192x192/192x384 |
168x168/168x336 |
|
箱体重量 |
Cabinet weight |
7.8kg(500«500) |
15.3kg (500x1000) |
|
箱体材质 |
Cabinet material |
Die casting aluminum |
Die casting aluminum |
|
維护方式 |
Maintenance way |
Front/Rear |
Front/Rear |
|
最佳视距 |
Best viewing distance |
&2.6m |
&2.9m |
|
最佳视角 |
Best viewing angle |
H:160°; V:160° |
H:160°;V:1608 |
|
驱动方式 |
Driving method (Constant Current) |
1/24 Scan |
1/21 Scan |
|
帧速率 |
Video frame rate |
260 Hz |
XOHz |
|
刷新率 |
Refresh rate |
1920-3840HZ |
1920-3840Hz |
|
亮度 |
Brightness |
&4500nit$ |
245Q0nits |
|
灰度等级 |
Grey Level |
12-16bit |
12-16bit |
|
昉护等级 |
Ingress protection |
IP65 |
IP65 |
|
平均功耗 |
Average power consumption |
360W |
360W |
|
Life Time |
Life Time |
>100,000 Hours |
>100,000 Hours |
|
The rate |
The rate |
<0.0002 |
<0.0002 |
|
项目 |
Item |
UN-3.91 |
UN-4.81 |
|
点间距 |
Pixel pitch |
3.91mm |
4.81 mm |
|
模组尺寸 |
Modulesize |
250*250mm |
250*250mm |
|
模组分辨率 |
Module resolution |
64x64 |
52x52 |
|
物理密度 |
Physical density |
65536 dots/m2 |
43264 dots/m2 |
|
灯珠类型 |
LED type |
SMD1921 |
SMD1921 |
|
箱体尺寸 |
Cabinet size |
500x500(1000)x84mm |
500x500(1000)x84mm |
|
箱体分辨率 |
Cabinet resolution |
128x128/128x256 |
104x104/104x208 |
|
箱体重量 |
Cabinet weight |
7.8kg(500*500) |
15.3kg(500*1000) |
|
箱体材质 |
Cabinet material |
Die casting aluminum |
Die casting aluminum |
|
维护方式 |
Maintenance way |
Front/Rear |
Front/Rear |
|
最佳视距 |
Best viewing distance |
，3.9m |
N4.8m |
|
最佳视角 |
Best viewing angle |
H:160°;V:160° |
H: 160°;V:160° |
|
驱动方式 |
Driving method (Constant Current) |
1/16 Scan, |
1/13 Scan |
|
帧速率 |
Video frame rate |
N60Hz |
N60 Hz |
|
刷新率 |
Refresh rate |
1920-3840Hz |
1920-3840HZ |
|
亮度 |
Brightness |
之 5000nits |
N5000nits |
|
灰度等级 |
Grey Level |
12-16bit |
12-16bit |
|
防护等级 |
Ingress protection |
IP65 |
IP65 |
|
平均功耗 |
Average power consumption |
360W |
360W |
|
Life Time |
Life Time |
>100,000 Hours |
>100,000 Hours |
|
The rate |
The rate |
<0.0002 |
<0.0002 |
