项目

Item

UN-4

UN-S

点间距

Pixel pitch

4mm

5mm

模组尺寸

Module size

320*160mm

320*160mm

横组分辨率

Module resolution

80*40

64x32

物理密度

Physical density

62500 dots/m²

40000 dots/m²

灯珠类型

LED type

SMD1921

SMD1921

箱体尺寸

Cabinet size

960x960x108mm

960*960x108mm

箱体分辨率

Cabinet resolution

240x240

192x192

箱体重置

Cabinet weight

28kg

28kg

箱体材质

Cabinet material

Die casting aluminum

Die casting aluminum

维护方式

Maintenance way

Rear

Rear

最佳祖距

Best view! ng distance

a4m

》5m

最佳视角

Best viewing angle

H: 140°;V:140°

H; 140°;V;14Q°

驱动方式

Driving method (Constant Current)

1/10Scan

1/8 Scan

帧速率

Video frame rate

&60 Hz

a60Hz

刷新率

Refresh rate

1920-3840Hz

1920-3840Hz

亮度

Brightness

&5500nits

^5500nits

灰度等级

Grey Level

12-16bit

12-16bit

防护等级

Ingress protection

IP65

IP65

平均功耗

Average power consumption

292W

292W

Life Time

Life Time

>100,000 Hours

>100,000 Hours

The rate

The rate

<0.0002

<0.0002
